Eaton FD3150L

EATON FD3150L C Series Type FD Molded Case Circuit Breaker, 600 VAC/250 VDC, 150 A, 35 kAIC at 480 VAC/65 kAIC at 240 VAC Interrupt, 3 Poles, Fixed Thermal/Fixed Magnetic Trip
Circuit Breakers
513301 FD3150L
Eaton
$0.00 / ea

Eaton FD3150L
  • actuator type: Handle
  • Amperage Rating: 150
  • Connection Type: Line/Load
  • Dimensions: 3.38 x 4.13 x 4.13
  • Enclosure Type: NEMA AB1/AB3
  • Frame: F
  • Frequency Rating: 50/60
  • Interrupt Rating: 35 kAIC at 480 VAC/65 kAIC at 240 VAC
  • Mounting Type: Panel
  • Number of Poles: 3
  • Phase: 3
  • Series: C Series
  • Temperature Rating: 40
  • Trip Type: Fixed Thermal/Fixed Magnetic
  • Type: Type FD
  • Voltage Rating: 600 VAC/250 VDC
  • Wire size: 4 to 4/0
Eaton Series C complete molded case circuit breaker, Series C, F-frame molded case circuit breaker, 150A, Three-pole, Line and load terminals, Thermal magnetic trip, FD breaker
QTY
Add to Wishlist
  • Features
  • All circuit breakers 10 to 50 A are suitable for HID (high intensity discharge) use
  • Suitable for reverse feed applications
  • 65 kA at 240 VAC, 35 kA at 480 VAC interrupt rating
