Woodhead 29T76
Woodhead reg; Safeway reg; 29T76 130145 3-Phase Female Heavy Duty Connector With Locking Blade, 480 VAC, 30 A, 3 Poles, 4 Wires, Yellow
Plugs Connectors
38335
29T76
Woodhead
$0.00
/ ea
- Amperage Rating: 30
- Color: Yellow
- Cord Diameter: 0.425 to 1.15
- Dimensions: 2.14 in Dia x 2.64 in L
- Grade: Industrial
- Material: Nylon
- Nema Rating: L16-30
- Number of Poles: 3
- Number Of Wires: 4
- Series: 130145
- Temperature Rating: -40 to 75
- terminal type: Screw
- Type: 3-Phase Female Heavy Duty
- Voltage Rating: 480
Woodhead® Safeway® Connector, 3-Phase Female Heavy Duty, Series: 130145, 480 VAC, 30 A, 3 Pole, 4 Wires, L16-30 NEMA Rating, Industrial Grade, 0.425 to 1.15 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Yellow, 2.14 in Dia x 2.64 in L Dimensions
- Features
- NEoTEX® paracril OZO rubber body yield the best performance for abrasion, chemical exposure and temperature extreme within the Super-Safeway® offering
- Rugged nylon body within the Safeway® offering provide exceptional durability and performance
- Color coded 1/4 in terminal screw preset in open position, ready to wire
- Wire screw terminal are tri-drive to be used with straight blade, Phillips® and square drive screw driver
- Floating blade construction provides self-alignment, and a better mechanical and electrical connection minimizing wear and heat generation
- Transparent wiring guide to verify all wire strand are in place before securing wire
- Captive, tri-drive head, stainless steel, speed screw provides easy assembly and long life
- 2-piece cord clamp strain relief include tri-drive screw to firmly secure the cord
- Stainless steel face screw
- Nylon face insert
- Brass wire saddle clamp
- Steel, zinc plated cord clamp screw
