Leviton ODC20-UDW
Leviton Provolt ODC20-UDW Line Voltage Self Contained Occupancy Sensor, 120 to 277 VAC, Ultrasonic Sensor, 2000 sq-ft Coverage, Ceiling Mount
Occupancy and Motion Sensors
7552966
ODC20-UDW
Leviton
$0.00
/ ea
- Amperage Rating: 60 to 30
- Color: White
- Connection Type: Wired
- Control Output: Automatic On/Off/Manual On
- Coverage: 2000
- Dimensions: 4.8 in Dia x 2.27 in H
- Enclosure Type: NEMA 4/10
- Mounting Type: Ceiling
- Response Frequency: 50/60
- Sensor Type: Ultrasonic
- Temperature Rating: 0 to 40
- Time Delay: 30 s to 30 min
- Type: Line Voltage Self Contained
- Voltage Rating: 120 to 277
24 VDC, 8-12 Ft Ceiling Mounted, Ulta-Sonic Occupancy Sensor OSC20-V0W, Kitted with Power Base OPB15 to Complete a Self Contained Line Voltage Sensor, White
- Features
- Utilizes sensors which emit non-audible sound waves and sense movement
- Any movement within the sensor's field of view causes a shift in the original emitted frequency, the sensor identifies the change as movement and controls light accordingly
- U/S models are immune to external ultrasonic signals from other sources such as white boards delivering uninterrupted performance
- Auto-adapting time delay and sensitivity are continually adjusted to occupancy pattern of use
- Delayed OFF timer the sensor will turn lights OFF if no motion is detected after a specified time
- Exclusive Walk-through feature provides increased energy savings by not leaving the lights ON for an extended period after only momentary occupancy
- Time delay and saved settings are protected during power outages and will return to the last known state
- Industry exclusive self-configuring local manual switch input, momentary or maintained switches are supported
- Presentation mode feature for slide or film presentations allows pushbuttons to turn lights OFF and keep them OFF while the room is occupied
- Manual switch and emergency override are class 1 and 2 circuits, class 2 circuits provided for flexibility
- Industry exclusive "fail safe" circuitry in the event of product failure, return to closed feature causes the relay to default ON which eliminates life safety concerns
- Industry exclusive HIS (high inrush stability) technology designed to handle today's high inrush electronic ballast loads and offer unmatched durability and service
- Robust and reliable mechanically held 10 A latching relay provides dependability and robust performance for all load types and provides energy savings over electronically held relays
- Adjustable time delay
- Configurable for manual ON/automatic OFF or automatic ON/automatic OFF
