RAB Lighting HAZPLED26CF
RAB HAZPLED26CF PLED Pendant Fixture,) LED Lamp, 28 W Fixture, 120/208/240/277 VAC, Gray Housing
IEC Pushbuttons - 22.5mm
7358359
HAZPLED26CF
RAB Lighting
$0.00
/ ea
- Amperage Rating: 0.25/0.13/0.12/0.11
- Average Life: 100000
- Ballast Type: Constant Current
- Color Rendering Index (CRI): 69
- Color Temperature: 5100
- Dimensions: 6-3/4 in H x 10 in W
- Enclosure Type: IP66
- Fixture Wattage: 28
- Housing Finish: Gray
- Housing Material: Die Cast Aluminum
- Lamp Type: LED
- Lamp Wattage: 26
- Lens Type: Clear Flat Glass
- Light Color: Cool White
- Lighting Technology: Multi-Chip
- Lumens: 2881
- Mounting Type: Pendant
- Series: PLED
- Voltage Rating: 120/208/240/277
RAB Pendant Fixture, Series: PLED, 120/208/240/277 VAC, 28 W Fixture, 0.25/0.13/0.12/0.11 A, Multi-Chip, LED Lamp, 26 W Lamp, 100000 hr Average Life, Cool White Light, 5100 K Color, 69 CRI, Constant Current Ballast, Clear Flat Glass Lens, 2881 Lumens, IP66, Pendant Mount, Die Cast Aluminum Housing, Gray Housing, 6-3/4 in H x 10 in W
- Features
- Resistant to shock and vibration
- Rugged construction ensures long life and safe operation
- 50/60 Hz frequency
- Closed cell silicone gasket gaskets
- Multi-chip high output, long life LED
- 100000 hr LED lifespan based on IES LM-80 results and TM-21 calculations lifespan
- LED color temperature is warranted to shift no more than 200 K in CCT over a 5 year period
- -40 deg C minimum starting temperature, 55 deg C maximum ambient temperature
- Ingress protection rating of IP66 for dust and water
- Superior heat sinking with external air flow fins
- Die cast aluminum housing, lens frame and mounting arm
- All external hardware is stainless steel
- Semi-specular aluminum reflector
- Our environmentally friendly polyester powder coatings are formulated for high durability and long lasting color and contain no VOC or toxic heavy metals
- Total harmonic distortion <20%, 95% power factor
- 3/4 in NPT threaded
- 0.25 A at 120 VAC, 0.13 A at 208 VAC, 0.12 A at 240 VAC, 0.11 A at 277 VAC
