Thomas & Betts MS248B

Pos-E-Kon® MS248B B Series Standard Terminal Insert, 48 Positions, 20 to 14 AWG Wire, Male Screw Connection, Glass Filled Thermoplastic
IEC Terminal Blocks
1560001 MS248B
Thomas & Betts
$0.00 / ea

Thomas & Betts MS248B
  • Connection Type: Male Screw
  • Material: Glass Filled Thermoplastic
  • Number Of Positions: 48
  • Series: B Series
  • Specifications: 16 A, 600 VAC
  • Suitable For Use With: B Series Connector
  • Temperature Rating: -40 to 257
  • Type: Standard
  • Wire size: 20 to 14
Pos-E-Kon® Terminal Insert, Standard, Series: B Series, 48 Positions, 20 to 14 AWG Wire, Male Screw Connection, For Use With: B Series Connector, -40 to 257 deg F, Specifications: 16 A, 600 VAC, Glass Filled Thermoplastic
QTY
Add to Wishlist
  • Features
  • 48 contacts with ground
  • Integral screw terminal contacts that provide for easy terminal wiring and fast assembly
  • Allows single access direction panel build wiring and easy terminal ID for service and testing
  • Standard wire protection saddles prevent cutting of strands during assembly
  • Standard size screw terminal
  • Use small blade screwdriver to push wire entry tab in for easy contact removal
