Thomas & Betts NJ12126
Carlon® Circuit Safe® NJ12126 Assembled NEMA Enclosure With Opaque Cover, 12 in W x 6 in D x 12 in H, NEMA 1/2/3/3S/3X/3SX/4/4X/12, Polycarbonate
Enclosure General Purpose
6857650
NJ12126
Thomas & Betts
$0.00
/ ea
- COLOR: Gray
- Cover Type: External Hinged
- Depth: 6
- Height: 12
- Lock: Latch
- Material: Polycarbonate
- Mounting Type: Wall
- Nema Rating: NEMA 1/2/3/3S/3X/3SX/4/4X/12
- Panel Size: 10.88 in W x 10.75 in H
- Temperature Rating: -30 to 230
- Type: Assembled
- Width: 12
Carlon® Circuit Safe® NEMA Enclosure, Assembled, 12 in Width, 6 in Depth, 12 in Height, NEMA 1/2/3/3S/3X/3SX/4/4X/12, External Hinged Cover, 10.88 in W x 10.75 in H Panel, Lock: Latch, Wall Mount, -30 to 230 deg F, Polycarbonate, Gray
- Features
- 100% non-metallic construction, including hinges
- Sturdy SS latches install without penetration of the enclosure base
- All cover screws are captive
- Panel suspension system allows the installation of panels at any depth, including stacking of multiple panels
- Non-metallic mounting rails for easy installation
- Less than half the weight of metal enclosures, 25% lighter than fiberglass, easier to handle and less expensive to ship
- 380 V/mil dielectric strength, 3 at 60 Hz, 2.96 at 106 Hz dielectric constant
