Thomas & Betts 2RAS18X
Sta-Kon® 2RAS18X Heat Shrinkable Insulated Butt Splice Connector, 22 to 18 AWG Conductor, 1-1/2 in L, Copper, Red
Butt Splice Connectors
273278
2RAS18X
Thomas & Betts
$0.00
/ ea
- Color: Red
- Conductor size: 22 to 18
- Dimensions: 1/4 in OD
- Finish: Electro-Tin Plated
- Length: 1-1/2
- Material: Copper
- Series: RA Series
- Specifications: 0.17 in Dia Maximum Insulation
- Temperature Rating: 150
- Type: Heat Shrinkable Insulated
- Voltage Rating: 600
Sta-Kon® Butt Splice Connector, Heat Shrinkable Insulated, Series: RA Series, 22 to 18 AWG Conductor, 1-1/2 in Length, 600 VAC, Specifications: 0.17 in Dia Maximum Insulation, 150 deg C, Copper, Red, Electro-TiN Plated, 1/4 in OD Dimensions
- Features
- Heat shrinkable with electro tin plated
- Self-insulated with heat shrinkable polyolefin and internally coated sealant
- Completed installation, a fully sealed connection is achieved to protect the joint against the degrading effects of galvanic action, corrosion and environmental exposure
