Thomas & Betts 54811

Color-Keyed® 54811 2-Way Long Barrel Splice Connector, 3/0 AWG Copper Conductor, Die Code: 50, 2-1/4 in L, Copper
Butt Splice Connectors
6921797 54811
Thomas & Betts
$0.00 / ea

Thomas & Betts 54811
  • Color Code: Orange
  • Conductor size: 3/0
  • Conductor Type: Copper
  • Die Code: 50
  • Length: 2-1/4
  • Material: Copper
  • Outside Diameter: 0.65
  • Specifications: Tin Plated
  • Type: 2-Way Long Barrel
  • Voltage Rating: 600
Color-Keyed® Splice Connector, 2-Way Long Barrel, Copper Conductor, 3/0 AWG Conductor, Die Code: 50, 600 VAC, 0.65 in OD, 2-1/4 in Length, Specifications: Tin Plated, Copper, Orange Color Code
QTY
Add to Wishlist
  • Features
  • 2-way connector provides high pullout values, easy-to insulate and provide a low resistance connection of high quality and low installed cost
  • Color coded for correct matching of installing die and connector
  • 354 kV max voltage
  • 325/24 = 131 kcmil wire size flex
