Thomas & Betts G2-PS-W

Sta-Kon® G2-PS-W G Series Non-Insulated Parallel Splice Connector, 2 AWG Conductor, 0.521 in OD Barrel, 0.64 in L, Copper
Butt Splice Connectors
7564461 G2-PS-W
Thomas & Betts
$0.00 / ea

Thomas & Betts G2-PS-W
  • Barrel Outer Diameter: 0.521
  • COLOR: Metallic
  • Conductor size: 2
  • Dimensions: 0.396 in ID
  • Finish: Tin Coated
  • Length: 0.64
  • Material: Copper
  • Series: G Series
  • Temperature Rating: 150
  • Type: Non-Insulated Parallel
  • Voltage Rating: 600
  • Wire Strip Length: 41/64
Sta-Kon® Splice Connector, Non-Insulated Parallel, Series: G Series, 2 AWG Conductor, 0.521 in OD Barrel, 0.64 in Length, 41/64 in Wire Strip Length, 600 VAC, 150 deg C, Copper, Metallic, Tin Coated, 0.396 in ID Dimensions
QTY
Add to Wishlist
  • Features
  • Resistant to corrosion and preserve the electrical integrity of the wires in single or multiple strands
  • Feature an intelligent constructible part number for quick identification of the wire range
  • Application tool WT115A, TBM8750M1, TBM8750BSCR
  • 52600 to 83700 kcmil circular mil range
