Thomas & Betts 256-30695-332
Color-Keyed® 256-30695-332 2-Hole Non-Insulated Compression Lug With Peep Hole, 350 kcmil Copper Conductor, Die Code: 71, 1/4 in Stud, Copper
Lug Compression Connectors
7299077
256-30695-332
Thomas & Betts
$0.00
/ ea
- Barrel Size: 0.93 in Dia
- Barrel Type: Standard
- Color: Red
- Conductor size: 350
- Conductor Type: Copper
- Die Code: 71
- Material: Copper
- Overall Length: 3.4
- Specifications: 3/4 in Stud Hole Spacing, Tin Plated
- Stud Size: 1/4
- Tongue Size: 1.81 in L x 1.36 in W x 0.18 in THK
- Type: 2-Hole Non-Insulated
- Voltage Rating: 35
Color-Keyed® Compression Lug, 2-Hole Non-Insulated, Copper Conductor, 350 kcmil Conductor, Die Code: 71, 35 kV, 1/4 in Stud, 1.81 in L x 1.36 in W x 0.18 in THK Tongue, 3.4 in Overall Length, Standard Barrel, 0.93 in Dia Barrel, Specifications: 3/4 in Stud Hole Spacing, Tin Plated, Copper, Red
- Features
- Peep hole
- High conductivity wrought copper
- 3/4 in hole spacing
