Thomas & Betts 54174
Color-Keyed® 54174 54100 1-Hole Non-Insulated Compression Lug With Peep Hole, 250 kcmil Copper Conductor, Die Code: 62, 3/8 in Stud, Copper
Lug Compression Connectors
36671
54174
Thomas & Betts
$0.00
/ ea
- Barrel Size: 0.77 in Dia
- Barrel Type: Standard
- Color: Yellow
- Conductor size: 250
- Conductor Type: Copper
- Die Code: 62
- Material: Copper
- Mounting Hole Size: 0.406
- Overall Length: 2.28
- Series: 54100
- Specifications: Tin Plated
- Stud Size: 3/8
- Tongue Size: 0.93 in L x 1.13 in W x 0.14 in THK
- Tongue Type: Straight
- Type: 1-Hole Non-Insulated
- Voltage Rating: 35
Color-Keyed® Compression Lug, 1-Hole Non-Insulated, Series: 54100, Copper Conductor, 250 kcmil Conductor, Die Code: 62, 35 kV, 3/8 in Stud, Straight Tongue, 0.93 in L x 1.13 in W x 0.14 in THK Tongue, 2.28 in Overall Length, Standard Barrel, 0.77 in Dia Barrel, Specifications: Tin Plated, 0.406 in Mounting Hole, Copper, Yellow
- Features
- Peep hole
- High conductivity wrought copper construction
- Tin plated finish
