Thomas & Betts 54851BE
Color-Keyed® 54851BE 54800 2-Hole Non-Insulated Compression Lug Connector, 8 AWG Copper Conductor, Die Code: 21, 1/4 in Stud, Copper
Lug Compression Connectors
6978985
54851BE
Thomas & Betts
$0.00
/ ea
- Barrel Size: 0.26 in Dia
- Barrel Type: Blind End/Long
- Color: Red
- Conductor size: 8
- Conductor Type: Copper
- Die Code: 21
- Material: Copper
- Mounting Hole Size: 0.281
- Overall Length: 2.313
- Series: 54800
- Specifications: 3/4 in Stud Hole Spacing, Tin Plated
- Stud Size: 1/4
- Tongue Size: 1.266 in L x 0.469 in W x 0.063 in THK
- Tongue Type: Straight
- Type: 2-Hole Non-Insulated
- Voltage Rating: 35
Color-Keyed® Compression Lug Connector, 2-Hole Non-Insulated, Series: 54800, Copper Conductor, 8 AWG Conductor, Die Code: 21, 35 kV, 1/4 in Stud, Straight Tongue, 1.266 in L x 0.469 in W x 0.063 in THK Tongue, 2.313 in Overall Length, Blind End/Long Barrel, 0.26 in Dia Barrel, Specifications: 3/4 in Stud Hole Spacing, Tin Plated, 0.281 in Mounting Hole, Copper, Red
- Features
- High conductivity wrought copper construction
