Thomas & Betts 1000HPS
Blackburn® 1000HPS Type HPS Split Bolt Connector With Spacer, 500 to 1000 kcmil ACSR/Stranded Aluminum/Copper Conductor, 2-1/4 x 4-1/32 in, Copper Alloy
Lug Mechanical Connectors
7602730
1000HPS
Thomas & Betts
$0.00
/ ea
- Bolt Size: 2-1/4 x 4-1/32
- Color: Metallic
- Conductor size: 500 to 1000
- Conductor Type: ACSR/Stranded Aluminum/Copper
- Finish: Electro-Plated Tin
- Material: Copper Alloy
- Specifications: 1.185 in Split, 2-17/32 in Hex Nut
- Type: Type HPS
Blackburn® Split Bolt Connector, Type HPS, ACSR/Stranded Aluminum/Copper Conductor, 500 to 1000 kcmil Conductor, 2-1/4 x 4-1/32 in Bolt, 1.185 in Split, 2-17/32 in Hex Nut, Copper Alloy, Electro-Plated Tin, Metallic
- Features
- Bolt and pressure bar of copper alloy completely tin plated for corrosion resistance, contoured spacer of bronze alloy copper
- Contoured spacer of bronze alloy copper
- Bolt and pressure bar of copper alloy completely tin plated
- Contoured spacer of electrolytic copper up through 4/0, bronze alloy 350 kcmil and above, all tin plated
- Blackburn® contax recommended when used on aluminum conductors
- Minimum tap with one max main 4/0 AWG stranded
