Thomas & Betts F71-TB
Sta-Kon® F71-TB F Series Non-Insulated Ring Terminal, 4 AWG Conductor, 1.16 in L, Brazed Seam/Serrated Barrel, Copper, Metallic
Ring Terminals
7058954
F71-TB
Thomas & Betts
$0.00
/ ea
- barrel type: Brazed Seam/Serrated
- COLOR: Metallic
- Conductor size: 4
- Finish: Tin Coated
- Length: 1.16
- Material: Copper
- Series: F Series
- Stud Size: 1/4
- Temperature Rating: 150
- Tongue Size: 0.48 in W
- Tongue Type: Large Ring
- Type: Non-Insulated
- Voltage Rating: 600
Sta-Kon® Ring Terminal, Non-Insulated, Series: F Series, 4 AWG Conductor, 1/4 in Stud, 1.16 in Length, Brazed Seam/Serrated Barrel, Large Ring Tongue, 0.48 in W Tongue, 600 VAC, 150 deg C, Copper, Tin Coated, Metallic
- Features
- Non-insulated ring terminals are made of electrolytic copper for high conductivity/corrosion resistance
- Can be installed with crimping tools having a single indenter or double indenter (recommended for solid wire)
- Serrated barrel to increases grip-on wire
- 200 pieces/pack
