Thomas & Betts KN8-8R-D

Spec-Kon® KN8-8R-D Large Ring Terminal, 8 AWG Conductor, 1.142 in L, Brazed Seam/Internal Serration Barrel, Red
Ring Terminals
7698590 KN8-8R-D
Thomas & Betts
$0.00 / ea

Thomas & Betts KN8-8R-D
  • barrel type: Brazed Seam/Internal Serration
  • COLOR: Red
  • Conductor size: 8
  • Finish: Tin Plated
  • Length: 1.142
  • Series: K Series
  • Specifications: Nylon Insulation
  • Stud Size: #8
  • Temperature Rating: 105
  • Tongue Size: 0.315 in W x 0.047 in THK
  • Tongue Type: Ring
  • Type: Large
  • Voltage Rating: 600
Spec-Kon® Ring Terminal, Large, Series: K Series, 8 AWG Conductor, #8 Stud, 1.142 in Length, Brazed Seam/Internal Serration Barrel, Ring Tongue, 0.315 in W x 0.047 in THK Tongue, 600 V, Specifications: Nylon Insulation, 105 deg C, Tin Plated, Red
QTY
Add to Wishlist
  • Features
  • Brazed seam ensures barrel does not separate during crimping
  • Internal barrel serrations
  • Ensures barrel does not separate during crimping
  • Molded funnel entry insulators ensure consistent shape and quality, shaped entry speeds installation and reduces wire hang up
  • Sleeve crimps wire insulation, providing high-vibration resistance and conductor strain-relief
  • Provides excellent chemical, impact and abrasion resistance
