Thomas & Betts RB724

Sta-Kon® RB724 RB Series Expanded Insulated Ring Terminal, 18 to 14 AWG Conductor, 1.16 in L, Copper, Blue
Ring Terminals
7331557 RB724
Thomas & Betts
$0.00 / ea

Thomas & Betts RB724
  • Barrel Size: 0.19 in OD
  • COLOR: Blue
  • Conductor size: 18 to 14
  • Finish: Tin Coated
  • Length: 1.16
  • Material: Copper
  • Series: RB Series
  • Specifications: 0.19 in Dia Maximum Insulation, Nylon Insulation
  • Stud Size: 5/16
  • Temperature Rating: 105
  • Tongue Size: 0.47 in W x 0.03 in THK
  • Tongue Type: Ring
  • Type: Expanded Insulated
  • Voltage Rating: 600
Sta-Kon® Ring Terminal, Expanded Insulated, Series: RB Series, 18 to 14 AWG Conductor, 5/16 in Stud, 1.16 in Length, 0.19 in OD Barrel, Ring Tongue, 0.47 in W x 0.03 in THK Tongue, 600 VAC, 0.19 in Dia Maximum Insulation, Nylon Insulation, 105 deg C, Copper, Tin Coated, Blue
QTY
Add to Wishlist
  • Features
  • Ring terminals won't fall-free even if the mounting screw loosens
  • Suffix X indicate an expanded insulation grip, means a wider wire entry to accommodate heavy wall insulation
