Thomas & Betts RC10-8FS
Sta-Kon® RC10-8FS RC Series Insulated Fork Terminal, 12 to 10 AWG Conductor, 0.97 in L, Brazed Seam/Serrated Barrel, Copper, Yellow
Ring Terminals
4283910
RC10-8FS
Thomas & Betts
$0.00
/ ea
- barrel type: Brazed Seam/Serrated
- COLOR: Yellow
- Conductor size: 12 to 10
- Finish: Electroplated Tin
- Length: 0.97
- Material: Copper
- Series: RC Series
- Specifications: 0.21 in Dia Maximum Insulation, 0.23 in Clearance, Nylon Insulation
- Stud Size: #8
- Temperature Rating: 105
- Tongue Size: 0.34 in W x 0.04 in THK
- Tongue Type: Flanged Fork
- Type: Insulated
- Voltage Rating: 600
Sta-Kon® Fork Terminal, Insulated, Series: RC Series, 12 to 10 AWG Conductor, #8 Stud, 0.97 in Length, Brazed Seam/Serrated Barrel, Flanged Fork Tongue, 0.34 in W x 0.04 in THK Tongue, 600 VAC, Specifications: 0.21 in Dia Maximum Insulation, 0.23 in Clearance, Nylon Insulation, 105 deg C, Copper, Electroplated Tin, Yellow
- Features
- Fork terminals allow easy installation because screw needs only to be loosened
- Brazed seam barrel is serrated for high pull-out value
- Insulation is Color coded
- A flanged-tongue fork with turned up tips provide extra holding protection
- WT112M, WT145A, WT145C, WT2000, ERG4001, ERG4003 recommended tools
