Thomas & Betts RC483
Sta-Kon® RC483 Insulated Ring Terminal, 12 to 10 AWG Conductor, 1.046 in L, Brazed/Overlapped Seam Barrel, Copper, Yellow
Ring Terminals
7542562
RC483
Thomas & Betts
$0.00
/ ea
- barrel type: Brazed/Overlapped Seam
- COLOR: Yellow
- Conductor size: 12 to 10
- Finish: Tin Coated
- Length: 1.046
- Material: Copper
- Series: RC Series
- Specifications: 0.28 in Clearance, Nylon Insulation
- Stud Size: #5
- Temperature Rating: 105
- Tongue Size: 0.277 in W x 0.04 in THK
- Tongue Type: Rectangle
- Type: Insulated
- Voltage Rating: 600
Sta-Kon® Ring Terminal, Insulated, Series: RC Series, 12 to 10 AWG Conductor, #5 Stud, 1.046 in Length, Brazed/Overlapped Seam Barrel, Rectangle Tongue, 0.277 in W x 0.04 in THK Tongue, 600 VAC, Specifications: 0.28 in Clearance, Nylon Insulation, 105 deg C, Copper, Tin Coated, Yellow
- Features
- Funneled barrel entry
- Deep internal serrations
- Made of copper and has electro-tin plating for corrosion-resistance
- 500 pieces/pack
