Hubbell Wiring HBL1283
Wiring Device-Kellems PresSwitch HBL1283 3-Way General Purpose Heavy Duty Standard Pushbutton Switch, 120 to 277 VAC, 20 A, 5540 W Power Rating, 2-Position Contact
IEC Pushbuttons - 22.5mm
24400
HBL1283
Hubbell Wiring
$0.00
/ ea
- Action: SPDT
- Actuator: Push Button
- Amperage Rating: 20
- Color: Brown
- Contact Configuration: 2-Position
- Dimensions: 3.28 x 1.5 x 1.45
- Environmental Conditions: -40 to 75
- Material: Thermoset
- Mounting: Threaded
- Number of Poles: 1
- Operating Cycles: 10000
- Power Rating: 5540
- Type: 3-Way General Purpose Heavy Duty Standard
- Voltage Rating: 120 to 277
Wiring Device-Kellems PresSwitch Pushbutton Switch, 3-Way General Purpose Heavy Duty Standard, 120 to 277 VAC, 20 A, 5540 W Power, 2-Position Contact Configuration, 1 Pole, SPDT Action, Push Button Actuator, Threaded Mounting, 10000 cycles Operating Cycles, Thermoset, Brown, Environmental Conditions: -40 to 75 deg C, 3.28 x 1.5 x 1.45 in
- Features
- Large brass binding head screws with deep slots
- Strip gauge for accurate wiring
- Thread cleaning captive mounting screw
