Hubbell Wiring GFSMCB240502P
Wiring Device-Kellems Circuit Guard GFSMCB240502P Heavy Duty GFCI Sensing Module Standard Circuit Breaker With Gasket, 120 VAC, 50 A, 10000 A Interrupt, 2 Poles, 0.025 s Shunt Trip
Circuit Breakers
7464134
GFSMCB240502P
Hubbell Wiring
$0.00
/ ea
- actuator type: Toggle
- Amperage Rating: 50
- Color: Black
- Connection Type: Screw Terminal
- Dimensions: 3 in L x 1.74 in W x 3 in H
- Enclosure Type: NEMA 4X
- Frame: Standard
- Frequency Rating: 60
- Interrupt Rating: 10000
- Material: Composite
- Number of Poles: 2
- Phase: 1
- Series: GFSMCB
- Temperature Rating: -40 to 75
- Trip Range: 4 to 6
- Trip Type: 0.025 s Shunt
- Type: Heavy Duty GFCI Sensing Module Standard
- Voltage Rating: 120
Wiring Device-Kellems, GFSMCB240502P, Circuit Breaker, Heavy Duty GFCI Sensing Module Standard, Series: GFSMCB, 120 VAC, 50 A, 60 Hz Frequency, 10000 A Interrupt, Standard Frame, 0.025 s Shunt Trip, 4 to 6 mA Trip, 2 Pole, 1 ph, Toggle Actuator, Screw Terminal Connection, NEMA 4X Enclosure, -40 to 75 deg C, 3 in L x 1.74 in W x 3 in H Dimensions, Composite, Black
