nVent Hoffman FS201286SSP0
nVent HOFFMAN FS201286SSP0 FS66S 2-Door Standard Duty Single Access Enclosure, 2078 mm L x 1216 mm W x 784 mm D, NEMA 3/3R/4/4X/12/13/IP66 NEMA Rating, 316 Stainless Steel
Enclosure General Purpose
7572427
FS201286SSP0
nVent Hoffman
$0.00
/ ea
- Depth: 784
- Finish: Brushed
- Length: 2078
- Lock: 3-Point Latch/Padlock
- Material: 316 Stainless Steel
- Mounting Type: Freestanding/Floor
- Nema Rating: NEMA 3/3R/4/4X/12/13/IP66
- Series: FS66S
- Type: 2-Door Standard Duty Single Access
- Width: 1216
nVent HOFFMAN Enclosure, 2-Door Standard Duty Single Access, Series: FS66S, 2078 mm Length, 1216 mm Width, 784 mm Depth, NEMA 3/3R/4/4X/12/13/IP66, Lock: 3-Point Latch/Padlock, Freestanding/Floor Mount, 316 Stainless Steel, Brushed
- Features
- Internal grid mounting system and PROLINE frame compatible for easy and fast panel installation
- Enclosure with contents to support standard duty 1102 lb evenly distributed and heavy duty 2205 lb evenly distributed
- Uni-body design with seams continuously welded and ground smooth
- 2-door enclosures provided with a removable center post for easy panel installation
- Heavy duty stainless steel lifting eyes
- Heavy duty three-point latching mechanism operated by 316L stainless steel POWERGLIDE™ padlocking handle on all doors
- Seamless foam in place gasket assures a water-tight and dust-tight seal
- Body flange trough collar channels liquids and contaminants away from door opening and installed equipment
- Removable hidden hinges
- Built-in plinth base that allows for flexible cable entry
- Painted or galvanized back panels can be rear-mounted in single access enclosures and back-to-back in dual access enclosures
- Bonding provision on door
