Hubbell Wiegmann PBXD16V

WIEGMANN PBXD16V PBXD EXTRA DEEP OPERATOR INTERFACE VERTICAL PUSHBUTTON ENCLOSURE, 6-1/4 IN W X 4.81 IN D, 16 OUTLETS, NEMA 4/12/13, CARBON STEEL
Enclosure Pushbutton
4944333 PBXD16V
Hubbell Wiegmann
$0.00 / ea

Hubbell Wiegmann PBXD16V
  • Capacity: 623.797
  • Color: Gray
  • Cover Type: Screw
  • Depth: 4.81
  • Finish: Polyester Powder Coated/Textured
  • Material: Carbon Steel
  • Mounting Type: Wall
  • Nema Rating: NEMA 4/12/13
  • Number of Outlets: 16
  • Series: PBXD
  • Type: Extra Deep Operator Interface Vertical
  • Width: 6-1/4
Wiegmann Pushbutton Enclosure, Extra Deep Operator Interface Vertical, Series: PBXD, 6-1/4 in Width, 4.81 in Depth, NEMA 4/12/13, Screw Cover, 16 Outlets, 623.797 cu-in, Wall Mount, Carbon Steel, Polyester Powder Coated/Textured, Gray
QTY
Add to Wishlist
  • Features
  • Bodies and doors fabricated from 14 ga steel
  • Continuously welded seams ground smooth
  • Closed cell oil-resistant neoprene gasket
  • External mounting plates, top and bottom of enclosure
  • Captivated cover screws thread into sealed wells
  • Standard 4-way pushbutton holes accept all brands of oiltight pushbuttons, switches and pilot lights
  • Enclosures have internal detachable hinges to hold cover open during wiring, yet permit quick removal
  • Grounding provisions provided
  • Provides protection from dust, dirt, oil and water
  • Extra deep design accommodates additional contact blocks for pushbuttons
