Littelfuse LPSM0003ZQCID

Littelfuse POWR-SAFE LPSM0003ZQCID Dead Front Indicating Fuse Holder, 600 VAC/VDC, 30 A, 3 Poles
Fuse Holders and Blocks
7005479 LPSM0003ZQCID
Littelfuse
$0.00 / ea

Littelfuse LPSM0003ZQCID
  • Amperage Rating: 30
  • Class: Midget
  • Color: White
  • Connection Type: Quick-Connect
  • Dimensions: 2.102 in W x 2.35 in D x 3.15 in H
  • Material: Thermoplastic
  • Mounting Type: DIN Rail
  • Number of Poles: 3
  • Series: LPSM
  • Suitable For Use With: Midget 10 x 38 mm Fuse
  • Type: Dead Front Indicating
  • Voltage Rating: 600
The LPSM midget fuse holder series is a dead front design providing protection to personnel when installing and removing fuses. The compact fuse holder mounts quickly onto 35 mm DIN rail, decreasing panel layout and assembly time. This product has two Quick Connect terminals on both the top and bottom of the holder, offering an additional connection option. It is available in 1-, 2-, 3- and 4-pole configurations.
QTY
Add to Wishlist
  • Features
  • Dual 1/4 in quick connect terminals on top and bottom of holder
  • Meets dead front requirements
  • Mountable on 35 mm DIN rail
  • Local LED indication
