Wire & Cable 41171002
Southwire reg; SIMpull reg; 41171002 Type THHN/THWN/MTW Building Wire, Spool Packaging, 600 VAC, (1) 4 AWG Stranded Copper Conductor, 500 ft L, Orange
Colored THHN Copper Wire
6765616
41171002
Wire & Cable
$0.00
/ ft
- Amperage Rating: 85
- Conductor size: 4
- Conductor Type: Stranded Copper
- Insulation Material: PVC
- Jacket Color: Orange
- Jacket Material: Nylon
- Length: 500
- Number of Conductors: 1
- Outside Diameter: 318
- Packaging Type: Spool
- Strands: 19
- Temperature Rating: 90
- Type: Type THHN/THWN/MTW
- Voltage Rating: 600
Southwire SIMpull Building Wire, Type THHN/THWN/MTW, Spool Packaging, 600 VAC, 85 A, 1 Conductor, Stranded Copper Conductor, 4 AWG Conductor, 318 mil OD, 500 ft Length, 19 Strands, PVC Insulation, Nylon Jacket, Orange Jacket, 90 deg C
- Features
- Thermoplastic insulation/SIM nylon sheath
- Heat, moisture gasoline and oil-resistant
- Sim Technology® for easier pulling
- Southwire® SIMpull THHN® or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders and branch circuits in commercial or industrial applications as specified in the 2011 national electrical code
- SIMpull THHN® conductors are designed to be installed without application of pulling lubricant
