Panduit PISR2-1
Panduit Pan-Lug Multi-Tap Splicer/Reducer, Dual Rated In-Line, Series: PISR, Aluminum/Copper/Stranded/Solid Conductor, 14 to 2 AWG, 10 to 8 AWG Conductor, Screw, 600 VAC, 0.94 in L Wire Strip, 3/16 in Hex Screw 120 in-lb Tightening Torque, Clear Insulation, 90 deg C, Aluminum/PVC, 2.38 in L x 0.75 in W x 1.25 in H
Supporting Information
- Flexible design can be used as a splice or reducer|Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation|Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance|Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion|Wide wire range taking capability minimizes inventory requirements|Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- Flexible design can be used as a splice or reducer
- Each port pre-filled with oxide inhibiting joint compound seals out air and moisture to deter surface oxidation
- Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance
- Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion
- Wide wire range taking capability minimizes inventory requirements
- Plated steel or aluminum set screw provides high strength, durable electrical contact between conductor and connector
- Brand: PanduitConductor size: 14 to 2 AWG, 10 to 8 AWGConductor Type: Aluminum/Copper/Stranded/SolidDimensions: 2.38 in L x 0.75 in W x 1.25 in HInstallation Type: ScrewMaterial: Aluminum/PVCSeries: PISRSpecifications: 0.94 in L Wire Strip, 3/16 in Hex Screw 120 in-lb Tightening Torque, Clear InsulationTemperature Rating: 90Type: Dual Rated In-LineVoltage Rating: 600
