Panduit LCAN600-12-6
Panduit Pan-Lug LCAN600-12-6 1-Hole Compression Connector Lug, 600 kcmil Stranded Copper Conductor, Die Code: P94, 42.767 in Stud, Tin Plated Copper
Lug Compression Connectors
7268480
LCAN600-12-6
Panduit
$0.00
/ ea
- Barrel Size: 0.92 in ID x 1.19 in OD x 1.75 in L
- Barrel Type: Standard
- Color: Green
- Conductor size: 600
- Conductor Type: Stranded Copper
- Die Code: P94
- Material: Tin Plated Copper
- Mounting Hole Size: 1.81
- Overall Length: 4.22
- Series: LCAN
- Specifications: 1-13/16 in L Wire Strip
- Stud Size: 42.767
- Temperature Rating: 90
- Tongue Size: 1.19 in W x 0.33 in THK
- Tongue Type: Straight
- Type: 1-Hole
- Voltage Rating: 35
Panduit Pan-Lug Compression Connector Lug, 1-Hole, Series: LCAN, Stranded Copper Conductor, 600 kcmil Conductor, Die Code: P94, 35 kV, 42.767 in Stud, Straight Tongue, 1.19 in W x 0.33 in THK Tongue, 4.22 in Overall Length, Standard Barrel, 0.92 in ID x 1.19 in OD x 1.75 in L Barrel, 1-13/16 in L Wire Strip, 90 deg C, 1.81 in Mounting Hole, Tin Plated Copper, Green
- Features
- Narrow tongue width for limited space applications
- Color-coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
