Panduit LCB1-38-E

Panduit Pan-Lug LCB1-38-E 1-Hole Compression Connector Lug, 1 AWG Copper Stranded Conductor, Die Code: P37, 42.95 in Stud, Tin Plated Copper
Lug Compression Connectors
6799904 LCB1-38-E
Panduit
$0.00 / ea

Panduit LCB1-38-E
  • Barrel Size: 0.36 in ID x 0.47 in OD x 1.36 in L
  • Barrel Type: Long
  • Color: Green
  • Conductor size: 1
  • Conductor Type: Copper Stranded
  • Die Code: P37
  • Material: Tin Plated Copper
  • Mounting Hole Size: 1.44
  • Overall Length: 2.57
  • Series: LCB
  • Specifications: 1-7/16 in L Wire Strip
  • Stud Size: 42.95
  • Temperature Rating: 90
  • Tongue Size: 0.7 in W x 0.11 in THK
  • Tongue Type: Straight
  • Type: 1-Hole
  • Voltage Rating: 35
Panduit Pan-Lug Compression Connector Lug, 1-Hole, Series: LCB, Copper Stranded Conductor, 1 AWG Conductor, Die Code: P37, 35 kV, 42.95 in Stud, Straight Tongue, 0.7 in W x 0.11 in THK Tongue, 2.57 in Overall Length, Long Barrel, 0.36 in ID x 0.47 in OD x 1.36 in L Barrel, 1-7/16 in L Wire Strip, 90 deg C, 1.44 in Mounting Hole, Tin Plated Copper, Green
QTY
Add to Wishlist
  • Features
  • Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
  • Color-coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
  • Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
  • Tin plated to inhibit corrosion
  • Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
  • Without inspection window
