Panduit LCB4-14-L
Panduit Pan-Lug LCB4-14-L LCB 1-Hole Compression Connector Lug, 4 to 3 AWG, 2 AWG Stranded Copper Conductor, Die Code: P29, 42.826 in Stud, Tin Plated Copper
Lug Compression Connectors
29766
LCB4-14-L
Panduit
$0.00
/ ea
- Barrel Size: 0.28 in ID x 0.38 in OD x 1.05 in L
- Barrel Type: Long
- Color: Gray
- Conductor size: 4 to 3 AWG, 2 AWG
- Conductor Type: Stranded Copper
- Die Code: P29
- Material: Tin Plated Copper
- Mounting Hole Size: 1.13
- Overall Length: 1.95
- Series: LCB
- Specifications: 1-1/8 in L Wire Strip
- Stud Size: 42.826
- Temperature Rating: 90
- Tongue Size: 0.55 in W x 0.09 in THK
- Tongue Type: Straight
- Type: 1-Hole
- Voltage Rating: 35
Panduit Pan-Lug Compression Connector Lug, 1-Hole, Series: LCB, Stranded Copper Conductor, 4 to 3 AWG, 2 AWG Conductor, Die Code: P29, 35 kVAC, 42.826 in Stud, Straight Tongue, 0.55 in W x 0.09 in THK Tongue, 1.95 in Overall Length, Long Barrel, 0.28 in ID x 0.38 in OD x 1.05 in L Barrel, Specifications: 1-1/8 in L Wire Strip, 90 deg C, 1.13 in Mounting Hole, Tin Plated Copper, Gray
- Features
- Tin plated to inhibit corrosion
- Color coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
- Long barrel maximizes number of crimps and provides premium wire pullout strength and electrical performance
- Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
- High conductivity seamless copper tube
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
- Without inspection window
- For use with stranded copper conductors
