Panduit LCC3/0-12-X

Panduit Pan-Lug LCC3/0-12-X 2-Hole Compression Lug, 3/0 AWG Stranded Copper Conductor, Die Code: P50, 42.767 in Stud, Copper
Lug Compression Connectors
29752 LCC3/0-12-X
Panduit
$0.00 / ea

Panduit LCC3/0-12-X
  • Barrel Size: 0.51 in ID x 0.64 in OD x 1.5 in L
  • Barrel Type: Long
  • Color: Orange
  • Conductor size: 3/0
  • Conductor Type: Stranded Copper
  • Die Code: P50
  • Material: Copper
  • Mounting Hole Size: 1.56
  • Overall Length: 5.03
  • Series: LCC
  • Specifications: 1-3/4 in Stud Hole Spacing, 1-9/16 in L Wire Strip, Tin Plated Finish
  • Stud Size: 42.767
  • Temperature Rating: 90
  • Tongue Size: 0.96 in W x 0.13 in THK
  • Tongue Type: Standard/Straight
  • Type: 2-Hole
  • Voltage Rating: 35
Panduit Pan-Lug Compression Lug, 2-Hole, Series: LCC, Stranded Copper Conductor, 3/0 AWG Conductor, Die Code: P50, 35 kV, 42.767 in Stud, Standard/Straight Tongue, 0.96 in W x 0.13 in THK Tongue, 5.03 in Overall Length, Long Barrel, 0.51 in ID x 0.64 in OD x 1.5 in L Barrel, Specifications: 1-3/4 in Stud Hole Spacing, 1-9/16 in L Wire Strip, Tin Plated Finish, 90 deg C, 1.56 in Mounting Hole, Copper, Orange
QTY
Add to Wishlist
  • Features
  • Long barrel maximizes number of crimps and provides premium wire pull-out strength and electrical performance
  • Color-coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
  • Enclosed barrel prevents corrosive material from entering barrel when used in harsh environments
  • Tin-plated to inhibit corrosion
  • For use with stranded copper conductors
  • Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
