Panduit LCD3/0-38D-X
Panduit Pan-Lug LCD3/0-38D-X 2-Hole Compression Connector Lug, 3/0 AWG Stranded Copper Conductor, Die Code: P50, 42.95 in Stud, Tin Plated Copper
Lug Compression Connectors
7371278
LCD3/0-38D-X
Panduit
$0.00
/ ea
- Barrel Size: 0.51 in ID x 0.64 in OD x 1.14 in L
- Barrel Type: Standard
- Color: Orange
- Conductor size: 3/0
- Conductor Type: Stranded Copper
- Die Code: P50
- Material: Tin Plated Copper
- Mounting Hole Size: 1.19
- Overall Length: 3.33
- Series: LCD
- Specifications: 1 in Stud Hole Spacing, 1-3/16 in L Wire Strip
- Stud Size: 42.95
- Temperature Rating: 90
- Tongue Size: 0.96 in W x 0.13 in THK
- Tongue Type: Straight
- Type: 2-Hole
- Voltage Rating: 35
Panduit Pan-Lug Compression Connector Lug, 2-Hole, Series: LCD, Stranded Copper Conductor, 3/0 AWG Conductor, Die Code: P50, 35 kV, 42.95 in Stud, Straight Tongue, 0.96 in W x 0.13 in THK Tongue, 3.33 in Overall Length, Standard Barrel, 0.51 in ID x 0.64 in OD x 1.14 in L Barrel, 1 in Stud Hole Spacing, 1-3/16 in L Wire Strip, 90 deg C, 1.19 in Mounting Hole, Tin Plated Copper, Orange
- Features
- Color-coded barrels marked with Panduit® and specified competitor die index numbers for proper crimp die selection
- Inspection window to visually assure full conductor insertion
- Tin plated to inhibit corrosion
- For use with stranded copper conductors
- Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
