Hubbell Killark FXS-22C
Killark Tumbler Switch, Dead End, Series: FXS, 120/277 VAC, 20 A, 2 Pole, 20 A at 120/277 VAC Contact, 1 Phase, Lever Actuator, NEMA 3CD/7CD/9EFG, Cast Aluminum, Gray, 6.63 in L x 6 in W x 4.38 in H Dimensions
Supporting Information
- Eliminates external sealing requirements|NEMA 3 weatherproof|Color coded wiring with more wiring space for easier field installation|Stainless steel captive screws for cover assembly|Lockout accessory available must be factory installed|Ground boss for grounding in the splice box|Operating shaft in both push buttons and selector switches are stainless steel
- 1 hp at 120 VAC/2 hp at 240 VAC power rating
- Test and reset push buttons are provided on cover assembly
- Exterior gasket provides NEMA 3 weatherproof protection
- Ground boss for grounding in the splice box
- Color coded wiring
- Captive cover bolts are made from stainless steel
- 3/4 in hub size
- Eliminates external sealing requirements
- Includes new GFI to meet latest UL943 GFCI standards revisions
- 60 Hz frequency
- Class A insulation
- 4 to 6 mA trip setting
- SP action
- Brand: Hubbell KillarkActuator: LeverAmperage Rating: 20Color: GrayContact Rating: 20 A at 120/277 VACDimensions: 6.63 in L x 6 in W x 4.38 in H
