Hubbell Wiring HBL2315
Locking Devices, Twist-LockĀ®, Industrial, InsulgripĀ® Flanged Inlet, 20A 125V AC, 2-Pole 3-Wire Grounding, NEMA L5-20P, Screw Terminal, Nylon casing, Back wired, White
Supporting Information
- Impact resistant thermoplastic construction|Backwired terminations for ease of installation
- Impact resistant thermoplastic construction
- Backwired terminations for ease of installation
- 32 to 10 AWG multiple drive terminal screws slotted, Phillips and Robertson
- Withstands 2000 VAC minimum dielectric voltage
- 16 to 8 AWG terminal accommodation
- Clear polycarbonate terminal retainer
- Brass blade material, NO 10 to 32 brass (white finish on neutral screw when used) multi-drive terminal screw, NO 10 to 32 brass (green finish) multi-drive ground screw
- 0.08 in steel nickel plated terminal clamp
- Steel zinc plated body holding screw
- Natural white nylon body contact carrier material and flanged casing material
- Nickel plated brass round head screws mounting screw material
- Brand:Ā Hubbell WiringAmperage Rating:Ā 20Color:Ā WhiteDimensions:Ā 2.88 x 2.88 x 2.09Enclosure:Ā NEMA 4/4X/12/IP44Grade:Ā IndustrialHorsepower:Ā 1Material:Ā NylonNema Rating:Ā L5-20PNumber of Poles:Ā 2Number Of Wires:Ā 3
