Hubbell Killark VR641C4
Killark VersaMate VR641C4 Type C Style I Feed-Through Receptacle and Back Box, 600 VAC, 250 VDC, 60 A, 4 Poles, 4 Wires, Gray
Receptacles
7620866
VR641C4
Hubbell Killark
$0.00
/ ea
- Amperage Rating: 60
- Color: Gray
- Dimensions: 10-7/8 in H x 4-1/2 in W x 4-1/2 in D
- Frequency Rating: 50 to 400
- Hub Size: 1-1/4
- Material: Copper Free Aluminum
- Nema Rating: NEMA 3/4/4X
- Number of Poles: 4
- Number Of Wires: 4
- Series: VR Series
- terminal type: Screw
- Type: Type C Style I Feed-Through
- Voltage Rating: 600 VAC, 250 VDC
1-1/4" 4W4P STYL2 60A RECEPT TYPE C
- Features
- Exclusive patented "Breech Lock" cap serves as either flip lid or screw cover
- Receptacle is NEMA 3R with lid snapped shut or NEMA 4X with lid turned shut or when VersaMate® plug is inserted and locking ring tightened
- Patented notch in cap arm holds cap open for easy plug insertion or maintenance
- Patented pin design uses slotted spring clip which avoids excessive wear while providing continuous electrical pin to sleeve contact
- VersaMate® receptacles use the same "increased safety" terminals and funnel design as VersaMate® plugs
- Exclusive "blind" receptacle mounting holes prevent moisture from entering box via thread cavities
