Hubbell Wiring HBL23CM10
Wiring Device-Kellems Twist-Lock HBL23CM10 1-Phase Flush Mount Grounding Single Screw Mount Corrosion-Resistant Locking Receptacle, 125 VAC, 30 A, 2 Poles, 3 Wires, Yellow
Receptacles
604442
HBL23CM10
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 30
- Color: Yellow
- Dimensions: 3.28 x 1.73 x 1.23
- Enclosure: IP20
- Horsepower: 1
- Material: Nylon
- Nema Rating: L5-20R
- Number of Poles: 2
- Number Of Wires: 3
- Temperature Rating: -40 to 75
- terminal type: Screw
- Type: 1-Phase Flush Mount Grounding Single Screw Mount Corrosion-Resistant
- Voltage Rating: 125
Locking Devices, Twist-LockпїЅ, Corrosion Resistant Single Flush Receptacle, 20A, 125V AC, 2 Pole, 3 Wire Grounding, Yellow
- Features
- 0.04 in brass terminal clamp material
- #10-32 bronze (white finish on neutral screw when used) terminal screw
- #10-32 brass (green finish) ground screw
- 0.04 in brass contact spring, ground contact and back plate
- Zinc plated steel mounting screws
- Black nylon cover (top), nylon polyester base
- 0.05 in brass bridge mounting strap
- Brass rivet, stainless steel auto ground clip
- Molded in or stamped on ratings
- Permanently ink marked on product catalog number
- Withstand 2000 VAC minimum dielectric voltage
- Certified for current interrupting at full rated current
- Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 0.75
- 20 A 12 AWG terminal accommodation
- Terminals identified in accordance with UL498 (x, y, z, white, green)
- HB or better per UL 94 or CSA 22.2 no. 0.6 flammability
- Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection
- Face color coding by voltage facilitates locating and mating of proper devices
- Nickel plated brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems
- Corrosion-resistant
