Hubbell Wiring HBL360RS1W
Wiring Device-Kellems Insulgrip HBL360RS1W 1-Phase Female Insulated Single Flanged Watertight Screw Mount Pin and Sleeve Receptacle, 600 VAC, 60 A, 2 Poles, 3 Wires, Black/Gray
Receptacles
6850916
HBL360RS1W
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 60
- Color: Black/Gray
- Dimensions: 4.25 in W x 4.66 in H
- Grade: Industrial
- Material: Thermoplastic
- Nema Rating: 4X
- Number of Poles: 2
- Number Of Wires: 3
- Temperature Rating: -40 to 75
- terminal type: Pressure Screw
- Type: 1-Phase Female Insulated Single Flanged Watertight Screw Mount
- Voltage Rating: 600
Heavy Duty Insulgrip Pin and Sleeve Devices, Industrial Grade Female Receptacle, 60A 600V AC, 2-Pole 3-Wire Grounding Style1,Terminal Screws
- Features
- Beryllium copper spring maintains high unit pressure on mating sleeves
- Closure cap with neoprene gasket for watertight seal when not in use
- O-ring provide a watertight and dusttight seal around pins negating contamination to the wire chamber
- Pin chamber confines arcing within the interior chamber
