Hubbell Wiring HBL360RS1W
Wiring Device-Kellems Insulgrip Pin and Sleeve Receptacle, 1-Phase Female Insulated Single Flanged Watertight Screw Mount, 600 VAC, 60 A, 2 Pole, 3 Wires, 4X NEMA Rating, Industrial Grade, -40 to 75 deg C, Pressure Screw Terminal, Thermoplastic, Black/Gray, 4.25 in W x 4.66 in H
Supporting Information
- Pin chamber confines arcing within the interior chamber|Watertight neoprene sealing glands for reliable seal|Spring-Loaded, gasketed cover for dust-tight seal
- Beryllium copper spring maintains high unit pressure on mating sleeves
- Closure cap with neoprene gasket for watertight seal when not in use
- O-ring provide a watertight and dusttight seal around pins negating contamination to the wire chamber
- Pin chamber confines arcing within the interior chamber
- Brand: Hubbell WiringAmperage Rating: 60Color: Black/GrayDimensions: 4.25 in W x 4.66 in HGrade: Industrial
