Hubbell Wiring HBL5292
Wiring Device-Kellems HBL5292 2-Circuit Grounding Heavy Duty Standard Straight Blade Combination Duplex Receptacle, 125/250 V, 15 A, 2 Poles, 3 Wires, Brown
Receptacles
467676
HBL5292
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 15
- Color: Brown
- Connection: Screw Terminal
- Environmental Conditions: -40 to 75
- Grade: Commercial/Industrial
- Horsepower: 1.5
- Material: Thermoplastic/Composite
- Mounting: Threaded
- Nema Rating: 5-15R/6-15R
- Number of Poles: 2
- Number Of Wires: 3
- Phase: 1
- Size: 3.28 x 1.5 x 0.88
- Type: 2-Circuit Grounding Heavy Duty Standard Straight Blade
- Voltage Rating: 125/250
- Wattage: 3750
- Wire size: 14 to 12
- Wiring Method: Back/Side Wired
Wiring Device-Kellems Combination Duplex Receptacle, 2-Circuit Grounding Heavy Duty Standard Straight Blade, 125/250 V, 15 A, 1.5 hp, 3750 W Wattage, 1 ph, 2 Pole, 3 Wires, 14 to 12 AWG Wire, 5-15R/6-15R NEMA Rating, 3.28 x 1.5 x 0.88 in Size, Screw Terminal Connection, Threaded Mounting, Commercial/Industrial Grade, Wiring Method: Back/Side Wired, Thermoplastic/Composite, Brown, Environmental Conditions: -40 to 75 deg C
