Hubbell Wiring HBL5352BK

Wiring Device-Kellems HBL HBL5352BK HBL5352 Series 1-Phase Compact Duplex Screw Mount Straight Blade Receptacle, 125 VAC, 20 A, 2 Poles, 3 Wires, Black
Receptacles
4487552 HBL5352BK
Hubbell Wiring
$0.00 / ea

  • Amperage Rating: 20
  • Color: Black
  • Dimensions: 3.28 x 1.33 x 1.05
  • Grade: Specification
  • Horsepower: 1
  • Material: Thermoplastic/Composite
  • Nema Rating: 5-20R
  • Number of Poles: 2
  • Number Of Wires: 3
  • Series: HBL5352 Series
  • Temperature Rating: -40 to 75
  • terminal type: Back and Side Wired Screw
  • Type: 1-Phase Compact Duplex Screw Mount
  • Voltage Rating: 125
Straight Blade Devices, Receptacles, Duplex, Industrial Grade, 2-Pole 3-Wire Grounding, 20A 125V, 5-20R, Black, Single Pack.
  • Features
  • HBL® extra heavy duty compact receptacles
  • Slender/compact design
  • Triple wipe contacts
  • Nylon face and RTB base
  • Brass contacts, mounting strap and terminal screws, plated brass wire clamp, stainless steel automatic self-grounding clip, steel-zinc plated mounting screws
  • Certified for current interrupting at full rated current
  • Withstands 2000 VAC minimum dielectric voltage
  • 12 to 10 AWG stranded or solid copper wire only
  • Terminals identified in accordance with UL 498 and CSA
