Hubbell Wiring HBL65W34
Wiring Device-Kellems Twist-Lock HBL65W34 1-Phase Grounding Standard Watertight Screw Mount Straight Blade Receptacle, 277 VAC, 15 A, 2 Poles, 3 Wires, Yellow
Receptacles
7566519
HBL65W34
Hubbell Wiring
$0.00
/ ea
- Amperage Rating: 15
- Color: Yellow
- Dimensions: 4.56 x 3.1 x 2.66
- Enclosure: NEMA 4/4X/6/6P/12
- Grade: Commercial/Industrial
- Horsepower: 2
- Material: Elastomer/Composite
- Nema Rating: L7-15R
- Number of Poles: 2
- Number Of Wires: 3
- Temperature Rating: -40 to 60
- terminal type: Screw
- Type: 1-Phase Grounding Standard Watertight Screw Mount
- Voltage Rating: 277
Wiring Device-Kellems Twist-Lock Straight Blade Receptacle, 1-Phase Grounding Standard Watertight Screw Mount, 277 VAC, 15 A, 2 hp, 2 Pole, 3 Wires, L7-15R NEMA Rating, Commercial/Industrial Grade, NEMA 4/4X/6/6P/12 Enclosure, -40 to 60 deg C, Screw Terminal, Elastomer/Composite, Yellow, 4.56 x 3.1 x 2.66 in
- Features
- Impact resistant PBT lid, cover plate and receptacle body
- Thermoplastic elastomer seal
- Stainless steel hardware and corrosion resistant connection points
