Woodhead 5541M
Woodhead® Cord Sealing Grip, Strain Relief, Series: 130099, 3/4 in Trade, MNPT Connection, 45 deg Angle, 9 in Mesh Length, Nylon, Green
Supporting Information
- Rugged construction suitable for boxes, cabinets, pushbutton and general use enclosures|Nylon body is resistant to impact and corrosion|Rubber grommet provides a liquid-tight seal and reduces cord pull-out|Grommets are color-coded for easy identification|Rubber grommet is best material to resist chemicals and handles a wide temperature range|Stainless steel mesh yields high strength, corrosion resistance and slight conductivity|Multi-hole available to accommodate a wide application range|Nylon gray threaded body and compression nut, nitrile PVC grommet, stainless steel grip, inner and outer ring, Mylar label|NEMA 3R rating|Half double and half single weave mesh|1 hole|Form 3 compression nut size|Without o-ring/locknut|Liquid-tight cord seal|For use with 130099-0144 3/4 in NPT MAX-LOC locknut 130099-0150 MAX-LOC 3/4 in NPT gasket sealing ring, 130180-0333 MAX-LOC 3/4 in NPT o-ring|9/16 to 11/16 in cable diameter
- Rugged construction suitable for boxes, cabinets, pushbutton and general use enclosures
- Nylon body is resistant to impact and corrosion
- Rubber grommet provides a liquid-tight seal and reduces cord pull-out
- Grommets are color-coded for easy identification
- Rubber grommet is best material to resist chemicals and handles a wide temperature range
- Stainless steel mesh yields high strength, corrosion resistance and slight conductivity
- Multi-hole available to accommodate a wide application range
- Nylon gray threaded body and compression nut, nitrile PVC grommet, stainless steel grip, inner and outer ring, Mylar label
- NEMA 3R rating
- Half double and half single weave mesh
- 1 hole
- Form 3 compression nut size
- Without o-ring/locknut
- Liquid-tight cord seal
- For use with 130099-0144 3/4 in NPT MAX-LOC® locknut 130099-0150 MAX-LOC® 3/4 in NPT gasket sealing ring, 130180-0333 MAX-LOC® 3/4 in NPT o-ring
- 9/16 to 11/16 in cable diameter
- Brand:Â WoodheadAngle:Â 45Color:Â GreenConnection Type:Â MNPT
