Lutron MS-Z101-LA
Maestro 0-10V dimmer occupancy/vacancy sensor, passive infrared, 8A fluorescent ballast or LED driver, 120-277V, in light almond
Supporting Information
- Rated for all drivers that provide a source current up to 8A switching LED driver/4.4A Fan (1/6 HP) with a 50mA max sink current, Neutral Optional|Screw Terminal and Wire-Lead Installation, 120V|Single Pole/Multi-location switching with Lutron Maestro Companion switches (MA-AS), Compatible with an existing 3-way switch|Features passive infrared (PIR) motion detection with exclusive Lutron XCT Technology for fine motion detection, which is 2-3x better at picking up motion than other manufacturers
- 0 to 10 VAC dimmer and vacancy PIR sensor, single pole/multi-location, single pole/multi-location, 8 A capacity
- Combined benefits of 0 to 10 VAC dimming and PIR occupancy/vacancy sensing to provide optimized dimming performance
- Superior sensing with Lutron®'s XCT sensing technology
- No neutral required, comes in occupancy/vacancy mode or vacancy only
- Controls 0 to 10 VAC electronic fluorescent ballasts, 0 to 10 V electronic LED drivers loads
- 8 A(electronic fluorescent ballast/LED driver), 1/6 hp at 4.4 A(fan)
- 400 sq-ft minor motion coverage
- 1/5/15/30 min (Adjustable) time delay
- Brand: LutronAmperage Rating: 8Color: Light AlmondCoverage: 900Dimensions: 4-11/16 in H x 2-15/16 in W x 1-7/16 in DMounting Type: Wall BoxResponse Frequency: 50/60Sensor Type: Passive InfraredSeries: MS-Z101Temperature Rating: 32 to 104Time Delay: 1 to 30
