Lutron PHPM-WBX-DV-WH
Lutorn phase adaptive power module dual voltage 3-wire fluorescent input, 120V
Supporting Information
- Provides dimming control for 1 zone of a full 16A lighting load|May be used to dim incandescent, halogen, electronic low-voltage, magnetic low-voltage, neon/cold cathode|Phase-adaptive technology automatically selects leading-edge or trailing-edge dimming for low-voltage transformers|Up to 3 power modules may be controlled by a single dimmer (C5-BMJ- will control only 1 module)|3-wire fluorescent dimmer input
- When connected to a 20 A circuit breaker, provides capacity on a 3 wire fluorescent dimmer for a full 16 A load of lighting
- Used to dim incandescent, halogen, electronic low voltage, magnetic low voltage, neon/cold cathode, Lutron® Tu-Wire® or Advance Mark X lighting sources
- Phase adaptive technology automatically selects leading edge or trailing edge dimming for low voltage transformers
- Up to 3 power modules may be controlled by a single dimmer
- Not for use with non-dim loads
- Surface or recess mount
- Power module is UL tested and approved for use in air plenums
- 0 to 40 deg C ambient operating temperature
- Relative humidity less than 90% non-condensing, indoor use only
- 1920 W capacity
- Brand: LutronAmperage Rating: 16Color: WhiteConnection Type: 12 AWG WireDimensions: 5.1 in H x 6.3 in W
