Lutron QSWS2-2BRLI-WH
Lutron SeeTouch QS Quantum GRAFIK Eye QS QSWS2-2BRLI-WH 2-Button Raise/Lower Insert Wall Switch Station, 24 to 36 VDC, 30 mA, White
Connected Lighting and Controls
7415773
QSWS2-2BRLI-WH
Lutron
$0.00
/ ea
- Amperage Rating: 30
- Color: White
- Control: Button
- Dimensions: 4-9/16 in H x 2-3/4 in W x 2 in D
- Finish: Matte
- Frequency Rating: 50/60
- Mounting Type: Wall Box
- Series: QSWS2
- Temperature Rating: 0 to 40
- Type: 2-Button Raise/Lower Insert
- Voltage Rating: 24 to 36
- Wire size: 18
GRAFIK Eye QS seeTouch QS Wallstation, 2-button wallstation w/raise/lower, insert style, matte finish
- Features
- Offers toggle functionality for any combination of zones ) in the system
- Receives up to two contact closure inputs via a connector on the back of the wall station
- Large, rounded buttons are easy to use
- Backlit buttons with optional engraving make it easy to find and operate the wall station in low light conditions
- Optional button engraving is angled up to the eye for easy reading
- The LEDs next to each button are used during programming and provide feedback when the buttons are pressed
