Lutron RMJ-16R-DV-B
Lutron PowPak RMJ-16R-DV-B Energi TriPak Wireless Relay Module With Softswitch, 120/277 VAC, 16 A, Surface Mount
Connected Lighting and Controls
7137254
RMJ-16R-DV-B
Lutron
$0.00
/ ea
- Amperage Rating: 16
- Color: Blue/White
- Dimensions: 3.94 in L x 2.82 in W x 1.25 in H
- Humidity: 0 to 90%
- Mounting Type: Surface
- Series: Energi TriPak™
- Temperature Rating: 0 to 55
- Voltage Rating: 120/277
Lutron PowPak Wireless Relay Module, Series: Energi TriPak, 120/277 VAC, 16 A, Surface Mount, 0 to 55 deg C, 0 to 90%, Blue/White, 3.94 in L x 2.82 in W x 1.25 in H
- Features
- Capable of switching 16 A of general purpose loads
- Optional low voltage dry contact closure output provides integration to building management systems, HVAC, VAV and more
- Receives wireless inputs from up to nine Pico® controls, six radio Powr Savr™ occupancy/vacancy sensors, and one radio Powr Savr™ daylight sensor
- Operates using clear Connect™ RF technology for reliable wireless communication
- RF range is 30 ft
- Mounts to a junction box through a standard half-inch (NPT trade size) knockout
- 0.5 hp at 120 VAC, 1.5 hp at 277 VAC motor rating, 431 MHz to 437 MHz radio frequency
- Complies with requirements for use in a compartment handling environmental air (plenum) per NEC® 2011 300.22(C)(3)
- Lutron patented technology prevents arcing of relay contacts, extending product lifetime
