ABB Installation Products CPC200
Clamp, One-Piece Cable and Pipe, EMT and Rigid Conduit Trade Size 2 Inches, Cable Outer Diameter Range 1.980-2.576 Inches, Steel
Supporting Information
- 1-piece, heavy duty construction ready-to install right out of the box, no need to break-apart and reassemble, no screws or bolts to drop|Heavy duty 5/16 in hex bolt with multi-driver head (Robertson square, Philips cross-recess and slot) provides a full range of installation options|Reconfigure wiring without complete disassembly|Remove cables easily without disturbing neighboring clamps|Parallel hook design keeps conduits and cable square with strut|Works with all depth of strut 13/16 to 3-1/4 in|2 hooks on the same side make the clamp easy-to install and keep conduits and cable square with strut|Rugged stirrup and wide saddle design holds securely with no damage to conduit or cable
- 1-piece, heavy duty construction ready-to install right out of the box, no need to break-apart and reassemble, no screws or bolts to drop
- Heavy duty 5/16 in hex bolt with multi-driver head (Robertson square, Philips® cross-recess and slot) provides a full range of installation options
- Reconfigure wiring without complete disassembly
- Remove cables easily without disturbing neighboring clamps
- Parallel hook design keeps conduits and cable square with strut
- Works with all depth of strut 13/16 to 3-1/4 in
- 2 hooks on the same side make the clamp easy-to install and keep conduits and cable square with strut
- Rugged stirrup and wide saddle design holds securely with no damage to conduit or cable
- Brand: ABB Installation ProductsConduit Size: 2Finish: Electro Galvanized/Silver GalvLoad Capacity: 200Material: SteelMounting Type: Parallel HookOutside Diameter: 1.98 to 2.576Series: 700Specifications: 35 ft-lb TorqueSuitable For Use With: EMT, Rigid Conduit and CableType: 1-Piece
