Hubbell Killark VR331C1
Killark VersaMate Receptacle and Back Box, Type C Style I Feed-Through, Series: VR Series, 600 VAC, 250 VDC, 30 A, 50 to 400 Hz, 3 Poles, 3 Wires, NEMA 3/4/4X, 1/2 in Hub, Screw Terminal, Copper Free Aluminum, Gray, 8-23/32 in H x 3-19/32 in W x 3-1/4 in D
Supporting Information
- Patented Breech-Lock cap serves as both flip lid and screw cover|Patented notch in cap arm holds cap open for easy plug insertion or maintenance|Type 4X rating when inserted into VersaMate receptacle and locking ring is tightened.Patented pin design uses slotted spring clip which avoids excessive wear while providing continuous electrical pin to sleeve contact|Increased Safety type box terminals with gripper ribs securely clamp around conductors
- Exclusive patented "Breech Lock" cap serves as either flip lid or screw cover
- Receptacle is NEMA 3R with lid snapped shut or NEMA 4X with lid turned shut or when VersaMate® plug is inserted and locking ring tightened
- Patented notch in cap arm holds cap open for easy plug insertion or maintenance
- Patented pin design uses slotted spring clip which avoids excessive wear while providing continuous electrical pin to sleeve contact
- VersaMate® receptacles use the same "increased safety" terminals and funnel design as VersaMate® plugs
- Exclusive "blind" receptacle mounting holes prevent moisture from entering box via thread cavities
- Brand: Hubbell KillarkAmperage Rating: 30Color: GrayDimensions: 8-23/32 in H x 3-19/32 in W x 3-1/4 in DFrequency Rating: 50 to 400Hub Size: 1/2Material: Copper Free AluminumNema Rating: NEMA 3/4/4XNumber of Poles: 3Number Of Wires: 3Series: VR Series
