Hubbell Wiring HBL5466CA

Wiring Device-Kellems Insulgrip HBL5466CA 1-Phase Grounding Portable Standard Cord Mount Straight Blade Plug, 250 VAC, 20 A, 2 Poles, 3 Wires, Black/White
Plugs Connectors
467782 HBL5466CA
Hubbell Wiring
$0.00 / ea

Straight Blade Devices, Male Plug, Insulgrip Heavy Duty, Industrial/Commercial Grade, Straight, 2-Pole 3- Wire Grounding, 20A 250V, 6-20P, Black and White, Single Pack.
  • Features
  • Withstands 2000 VAC dielectric voltage
  • Certified for current interrupting at full rated current
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise
  • Terminals identified in accordance with UL 498 (brass, white, green)
  • 18 to 10 AWG solid or stranded copper conductor terminal accommodation
  • UL 94-HB or better flammability rating
  • 0.06 in brass contact blades, 0.04 in copper alloy blades
  • #8-32 brass/nickel plated for neutral terminal screw, #8-32 brass multiple drive (green) ground screw
  • 8-position angled plug
  • Low profile design
  • Roomy wiring chamber provides ample space for wiring
  • Black nylon housing, clear polycarbonate retainer, natural nylon blade holder and cord clamp
