Hubbell Wiring HBL7567CY

Hubbell Insulgrip HBL7567CY Non-Grounding Locking Plug, 125/250 VAC, 10/15 A, 3 Poles, 3 Wires, Black
Plugs Connectors
4486227 HBL7567CY
Hubbell Wiring
$0.00 / ea

Hubbell Wiring HBL7567CY
Hubbell Insulgrip Locking Plug, Non-Grounding, 125/250 VAC, 10/15 A, 50/60 Hz, 3 Poles, 3 Wires, NEMA L10-20, Insulgrip Grade, IP20 Enclosure, 0.23 to 0.72 in Cord Dia, -40 to 75 deg C, Screw Terminal, Nylon, Black, 1.5 in Dia x 1.9 in L
QTY
Add to Wishlist
  • Features
  • Individually molded face for each blade configuration keeps debris out of plug interior
  • Ribbed nylon housing is impact and chemical resistant
  • Roomy wiring chamber provides ample space for wiring
  • Certified for current interrupting at full rated current
  • Dielectric voltage withstands 2000 VAC minimum
  • 18 to 10 AWG stranded copper wire only
  • Natural nylon blade/contact carrier
  • Clear polycarbonate terminal retainer material
  • Natural nylon cord clamp
  • Brass blades/contact
  • Brass grounding screw
  • Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 0.75
  • Molded in/stamped on ratings
