Stahlin C3024
Stahlin C3024 Base Configuration Control Disconnect Enclosure, 24 in W x 10 in D x 30 in H, NEMA 1/3/3R/4X/12/IP66/IK10, Fiberglass Reinforced Polyester
Enclosures Non-Metallic
508610
C3024
Stahlin
$0.00
/ ea
- Color: Glacier Gray
- Cover Type: Hinged/Opaque
- Depth: 10
- Height: 30
- Material: Fiberglass Reinforced Polyester
- Nema Rating: NEMA 1/3/3R/4X/12/IP66/IK10
- Panel Size: 21.38 in W x 26.88 in H
- Series: C Series
- Temperature Rating: -76 to 274
- Type: Base Configuration
- Width: 24
The Stahlin Disconnect Series was designed for use in larger industrial control systems and machine tool control panels. The disconnect handle is made from a corrosion resistant composite for extreme environment conditions. The design is easily adaptable
- Features
- These enclosures are corrosion-resistant and are designed around a type 4X watertight, corrosion-resistant vertical disconnect handle
- The Stahlin disconnect series was designed for use in larger industrial control systems and machine tool control panels
- The vertical disconnect handle is made from a corrosion-resistant composite for extreme environment conditions
- The design is easily adaptable
- Without pre-mounted control
- Stands up to an exceptionally broad range of chemical exposures
- Molded-in panel mounting inserts
- Integral mounting feet
