Thomas & Betts 10RC-250T
Sta-Kon® 10RC-250T 250 Insulated Male Tab, 12 to 10 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Brass/Copper, Yellow
Terminal Male Disconnects
37528
10RC-250T
Thomas & Betts
$0.00
/ ea
- Barrel Type: Brazed Seam
- Color: Yellow
- Conductor size: 12 to 10
- Dimensions: 1.08 in L
- Finish: Electro Plated Tin
- Material: Brass
- Series: 250
- Specifications: 1/4 in Maximum Insulation, 0.04 in Stock
- Tab Size: 0.25 in W x 0.032 in THK
- Temperature Rating: 105
- terminal type: Crimp
- Type: Insulated
- Voltage Rating: 600
Sta-Kon® Male Tab, Insulated, Series: 250, 12 to 10 AWG Conductor, 0.25 in W x 0.032 in THK Tab, Brazed Seam Barrel, Crimp Terminal, 600 VAC, 0.04 in THK Stock, 1/4 in Dia Maximum Vinyl Insulation, 105 deg C, Brass/Copper, Yellow, Tin Electro-Plated, 1.08 in L
- Features
- Brazed seam serrated barrel provides maximum tensile strength
