Woodhead 113022A01F030

Brad reg; Mini-Change reg; 113022A01F030 130010 Double Ended Straight Cordset, Female x Male Connector, 3 ft L Cable, 3 Poles, Single Keyway
Sensor Cables and Connection Systems
7367468 113022A01F030
Woodhead
$0.00 / ea

Woodhead 113022A01F030
  • Amperage Rating: 13
  • Angle: 90
  • Cable Length: 3
  • Cable Material: PVC
  • Cable Type: STOOW
  • Connector Material: PVC
  • Connector Type: Female x Male
  • Keyway: Single
  • Number of Poles: 3
  • Series: 130010
  • Type: Double Ended Straight
  • Voltage Rating: 600
  • Wire Pin Colors: Green/Black/White
Brad® Mini-Change® Cordset, Double Ended Straight, Series: 130010, Female x Male Connector, PVC, STOOW Cable, 3 ft Cable Length, PVC Cable, 3 Pole, Single Keyway, 600 VAC/VDC, 13 A, 90 deg, Wire Pin Colors: Green/Black/White
QTY
Add to Wishlist
  • Features
  • IP68 rating
  • Male-female gender
  • Single keyway
  • Patented, Quad Beam™ socket contact with stainless steel sleeve
  • Maintains consistent pressure on the male pin to ensure optimum conductivity
  • High performance, long lasting plating that maintains low resistance through many mate/unmate cycles
  • Molded key indicator
  • Easier alignment and mating of connector
  • Provides 100 lb minimum cable strain relief radiates stress in side-loaded conditions
